Model 100E Instruction Manual Getting Started
045150102 Rev XB1 41
3.3. Initial Calibration
3.3.1. Basic Calibration Procedure
The following three-step procedure assumes that the instrument does not have any of
the available zero/span (Z/S) or IZS valve options installed. Chapter 7 contains
instructions for calibrating instruments with valve options. Chapter 8 contains directions
for performing for EPA protocol calibrations.
The initial calibration should be carried out with the analyzer’s reporting range for
SINGLE range mode with a range span of 500 PPB (factory default settings for most
units). This will enable you to compare your results to the factory calibration.
STEP ONE: Set/verify the analog output reporting range of the M100E:
SETUP X.X RANGE CONTROL MENU
MODE SET UNIT EXIT
Press this button to set
the analyzer for
SNGL
DUAL or AUTO ranges
SETUP X.X RANGE: 500.0 CONC
0 0 5 0 0 .0 ENTR EXIT
To change the value of the
reporting range span, enter the
number by pressing the key under
each digit until the expected value
appears.
Press this button to select the
concentration units of measure:
PPB, PPM, UGM, MGM
EXIT ignores the new setting and
returns to the RANGE CONTROL
MENU.
ENTR accepts the new setting and
returns to the
RANGE CONTROL MENU.
SETUP X.X
CFG DAS RNGE PASS CLK MORE EXIT
SAMPLE RANGE = 500.000 PPB SO2 =X.XXX
< TST TST > CAL
SETUP
SETUP X.X RANGE: 500.0 Conc
0 0 0 5 0 .0
ENTR EXIT
STEP TWO: Set the expected SO
2
span gas concentration.
This sequence causes the
analyzer to prompt for the
expected SO
x
span
concentration.
M-P CAL SO2 SPAN CONC: 450.0 Conc
0 0 0
4 5 .0 ENTR EXIT
M-P CAL RANGE = 500.000 PPB SO2 =X.XXX
< TST TST > ZERO
CONC
EXIT
SAMPLE* RANGE = 500.000 PPB SO2 =X.XXX
< TST TST >
CAL
SETUP
The SO
2
span
concentration values
automatically default to
450.0 Conc
.
To change this value to
the actual concentration of
the span gas, enter the
number by pressing the
key under each digit until
the expected value
appears.
EXIT
ignores the new setting
and returns to the previous
display.
ENTR
accepts the new setting
and returns to the
previous display..
