Model 100E Instruction Manual Getting Started
045150102 Rev XB1 33
Table 3-5: NIST-SRM's Available for Traceability of SO
2
Calibration Gases
NIST-SRM
4
Type Nominal Concentration
1693a
1694a
1661a
Sulfur dioxide in N
2
Sulfur dioxide in N
2
Sulfur dioxide in N
2
50 ppm
100 ppm
500 ppm
No Valve Options Installed
MODEL
100E
Sample
Zero Air
Exhaust
Span
MODEL 701
Zero Air
Generator
VEN
T
Calibrated
SO
2
GAS
(At high
concentration)
Source of
SAMPLE Gas
Removed
during
Calibration
Valve
OR
Needle valve to
control flow
MODEL
100E
Sample
Zero Air
Exhaust
Span
MODEL 701
Zero Air
Generator
VENT
Calibrated
SO
2
GAS
(At span gas
concentration)
Source of
SAMPLE Gas
Removed
during
calibration
MODEL 700 Gas
Dilution
Calibrator
(with Ozone Bench
Option)
Figure 3-6: Basic Pneumatic Connections for Units Without Valve Options
