2. SPECIFICATIONS, APPROVALS AND
WARRANTY
2.1. Specifications
Table 2-1: Model 100E Basic Unit Specifications
Min/Max Range
(Physical Analog Output)
In 1ppb increments from 50ppb to 20 000ppb, dual ranges or auto
ranging
Measurement Units ppb, ppm, µg/m3, mg/m3 (user selectable)
Zero Noise
1
0.2 ppb RMS
Span Noise
1
0.2 ppb RMS
Lower Detectable Limit
2
0.4 ppb RMS
Zero Drift (24 hours) <0.5 ppb
Zero Drift (7 days) 1 ppb
Span Drift (7 Days) <0.5% FS
Linearity 1% of full scale
Precision 0.5% of reading1
Temperature Coefficient < 0.1% per
o
C
Voltage Coefficient < 0.05% per V
Lag Time
1
20 sec
Rise/Fall Time
1
95% in <100 sec
Sample Flow Rate 650cc/min. ±10%
Temperature Range 5-40oC
Humidity Range 0 - 95% RH, non-condensing
Dimensions H x W x D 7" x 17" x 23.5" (178 mm x 432 mm x 597 mm)
Weight, Analyzer
(Basic Configuration)
45 lbs (20.5 kg) w/internal pump
AC Power Rating 100 V, 50/60 Hz (3.25A);
115 V, 60 Hz (3.0 A);
220 – 240 V, 50/60 Hz (2.5 A)
Environmental Installation category (over-voltage category) II; Pollution degree 2
Analog Outputs Three (3) Outputs
Analog Output Ranges 100 mV, 1 V, 5 V, 10 V, 2-20 or 4-20 mA isolated current loop.
All Ranges with 5% Under/Over Range
Analog Output Resolution 1 part in 4096 of selected full-scale voltage
Status Outputs 8 Status outputs from opto-isolators
Control Inputs 6 Control Inputs, 3 defined, 3 spare
Serial I/O One (1) RS-232; One (1) RS-485 (2 connecters in parallel)
Baud Rate : 300 – 115200: Optional Ethernet Interface
Certifications USEPA: Reference Method Number EQOA-XXXX-XXX
CE: XXNNNNN-N:NN + XN:NN + XN:NN, XXNNNNN - Class A
1 As defined by the USEPA.
2 Defined as twice the zero noise level by the USEPA.
