Teledyne 100E - Dual Range Mode; Single Range Mode (SNGL)

Operating Instructions Model 100E Instruction Manual
66 045150102 Rev XB1
6.5.3. Single Range mode (SNGL)
The default range mode for the analyzer is single range, in which all analog concentration
outputs are set to the same reporting range. This reporting range can be set to any value
between 0.1 ppb and 20 000 ppb.
While the two outputs always have the same reporting range, the span and scaling of
their electronic signals may also be configured for different differently (e.g., A1 = 0-10
V; A2 = 0-0.1 V).
To select SNGLE range mode and to set the upper limit of the range, press:
SAMPLE* RANGE = 500.000 PPB SO2 =X.XXX
< TST TST > CAL
SETUP
SETUP C.3
PRIMARY SETUP MENU
CFG DAS
RNGE
PASS CLK MORE EXIT
SETUP C.3 RANGE CONTROL MENU
MODE
SET UNIT EXIT
SETUP C.3 RANGE MODE:
SNGL
SNGL
DUAL AUTO ENTR EXIT
EXIT
x 2 returns
to the main
SAMPLE
display
SETUP C.3 RANGE MODE:
SNGL
SNGL DUAL AUTO
ENTR
EXIT
SETUP C.3 RANGE CONTROL MENU
MODE
SET
UNIT EXIT
SETUP C.3 RANGE:
500.0 Conc
0 0
5 0 0 .0 ENTR
EXIT
SETUP C.3 RANGE CONTROL MENU
MODE SET UNIT
EXIT
6.5.4. Dual Range Mode
Selecting Dual Range mode allows the A1 and A2 outputs to be configured with different
Measurement Ranges. The analyzer software calls these two ranges Low and High. The
Low range setting corresponds with the analog output labeled A1 on the Rear Panel of
the instrument. The High Range Setting corresponds with the A2 output. While the
software names these two ranges Low and High, they do not have to be configured that
way. For example: The Low range can be set for a span of 0-150 ppm while the high
range is set for 0-50 ppm.
In DUAL range mode the RANGE test function displayed on the front panel will be
replaced by two separate functions:
RANGE1: The range setting for the A1 output.
RANGE2: The range setting for the A2 output.
