APPENDIX A-3: Warnings and Test Functions,
Revision B.3
Model 100E Instruction Manual
240 045150110 Rev B.3
APPENDIX A-3: Warnings and Test Functions, Revision B.3
Table A-2: M100E Warning Messages, Revision B.3
Name Message Text Description
WSYSRES SYSTEM RESET Instrument was power-cycled or the CPU was reset.
WDATAINIT DATA INITIALIZED Data storage was erased.
WCONFIGINIT CONFIG INITIALIZED Configuration storage was reset to factory configuration
or erased.
WPMT PMT DET WARNING PMT detector outside of warning limits specified by
DETECTOR_LIMIT variable.
WUVLAMP UV LAMP WARNING UV lamp reading outside of warning limits specified by
DETECTOR_LIMIT variable.
WSAMPFLOW SAMPLE FLOW WARN Sample flow outside of warning limits specified by
SAMP_FLOW_SET variable.
WSAMPPRESS SAMPLE PRESS WARN Sample pressure outside of warning limits specified by
SAMP_PRESS_SET variable.
WVACPRESS
5
VACUUM PRESS WARN Vacuum pressure outside of warning limits specified by
VAC_PRESS_SET variable.
WBOXTEMP BOX TEMP WARNING Chassis temperature outside of warning limits specified
by BOX_SET variable.
WRCELLTEMP RCELL TEMP WARNING Sample chamber temperature outside of warning limits
specified by RCELL_SET variable.
WIZSTEMP IZS TEMP WARNING IZS temperature outside of warning limits specified by
IZS_SET variable.
WPMTTEMP PMT TEMP WARNING PMT temperature outside of warning limits specified by
PMT_SET variable.
WDARKCAL
5
DARK CAL WARNING Dark offset above limit specified by DARK_LIMIT
variable.
WHVPS HVPS WARNING High voltage power supply output outside of warning
limits specified by HVPS_SET variable.
WDYNZERO CANNOT DYN ZERO Contact closure zero calibration failed while DYN_ZERO
was set to ON.
WDYNSPAN CANNOT DYN SPAN Contact closure span calibration failed while DYN_SPAN
was set to ON.
WREARBOARD REAR BOARD NOT DET Rear board was not detected during power up.
WRELAYBOARD RELAY BOARD WARN Firmware is unable to communicate with the relay board.
WFRONTPANEL FRONT PANEL WARN Firmware is unable to communicate with the front panel.
WANALOGCAL ANALOG CAL WARNING The A/D or at least one D/A channel has not been
calibrated.
