Model 100E Instruction Manual Getting Started
045150102 Rev XB1 35
3.2. Initial Operation
CAUTION
Do not look at the UV lamp while the unit is operating.
UV light can case eye damage.
Always use safety glasses
(plastic glasses will not do).
If you are unfamiliar with the M100E theory of operation, we recommend that you read
Section 10 before proceeding.
For information on navigating the analyzer’s software menus, see the menu trees
described in Appendix A.1.
Particulate Filter
ON/OFF
SWITCH
PS1
(+5 VDC;
±
15VDC)
PS2
(+12 VDC)
Pump Assy
Relay Board
Sensor
Housing
Vacuum
Manifold
Front Panel
Rear Panel
PC
104 Card
Mother
Board
Power
Receptacle
PMT Housing
PMT Preamp PCA
PMT Cooling System
UV Source Lap
Hydrocarbon Scrubber
(Kicker)
Hidden from view
Figure 3-8: M100E Layout (Basic Unit – No Valve Options)
