6.2.2. Warning Messages
The most common instrument failures will be reported as a warning on the analyzer’s
front panel and through the COM ports. Section 11.1.1 explains how to use these
messages to troubleshoot problems. Section 3.2.3 shows how to view and clear warning
messages. Table 6-3 lists all warning messages for the current version of software.
Table 6-3: List of Warning Messages
MESSAGE MEANING
ANALOG CAL WARNING
The instruments A/D circuitry or one of its analog outputs is not
calibrated.
AZERO WRN XXX.X MV
The reading taken during the auto-zero cycle is outside of specified limits.
The value XXX.X indicates the auto-zero reading at the time of the
warning.
BOX TEMP WARNING
The temperature inside the M200E chassis is outside the specified limits.
CANNOT DYN SPAN
Remote span calibration failed while the dynamic span feature was set to
turned on
CANNOT DYN ZERO
Remote zero calibration failed while the dynamic zero feature was set to
turned on
CONFIG INITIALIZED
Configuration was reset to factory defaults or was erased.
DARK CAL WARNING
Dark offset above limit specified indicating that too much stray lightis
present in the sample chamber
.
DATA INITIALIZED
iDAS data storage was erased.
FRONT PANEL WARN
Firmware is unable to communicate with the front panel.
HVPS WARNING
High voltage power supply for the PMT is outside of specified limits.
IZS TEMP WARNING
On units with IZS options installed: The permeation tube temperature is
outside of specified limits.
PMT DET WARNING PMT detector output outside of operational limits.
PMT TEMP WARNING
PMT temperature is outside of specified limits.
RCELL PRESS WARN
Sample chamber pressure is outside of specified limits.
RCELL TEMP WARNING
Sample chamber temperature is outside of specified limits.
REAR BOARD NOT DET
The CPU is unable to communicate with the motherboard.
RELAY BOARD WARN
The firmware is unable to communicate with the relay board.
SAMPLE FLOW WARN
The flow rate of the sample gas is outside the specified limits.
SAMPLE PRESS WARN Sample pressure outside of operational parameters.
SYSTEM RESET
The computer was rebooted.
UV LAMP WARNING
The
UV lamp intensity measured by the reference detector reading
too low or too high
