Teledyne 100E - Page 70

Operating Instructions Model 100E Instruction Manual
68 045150102 Rev XB1
To set individual ranges press the following keystroke sequence.
SAMPLE* RANGE = 500.000 PPB SO2 =X.XXX
< TST TST > CAL
SETUP
SETUP X.X
PRIMARY SETUP MENU
CFG DAS
RNGE
PASS CLK MORE EXIT
SETUP X.X RANGE CONTROL MENU
MODE
SET UNIT EXIT
SETUP X.X RANGE MODE:
SNGL
SNGL DUAL
AUTO
ENTR EXIT
EXIT
x 2 returns
to the main
SAMPLE
display
SETUP X.X RANGE MODE:
AUTO
SNGL DUAL AUTO
ENTR
EXIT
SETUP X.X RANGE CONTROL MENU
MODE
SET
UNIT EXIT
SETUP X.X HIGH RANGE:
500.0 Conc
0 0 5 0 0 .0 ENTR EXIT
SETUP X.X LOW RANGE:
500.0 Conc
0 0 5 0 0 .0 ENTR EXIT
Toggle the numeral
keys to set the
LOW
and
HIGH
range value.
ENTR accepts the
new setting, EXIT
ignores the new
setting.
NOTE
In AUTO range mode, the LOW and HIGH ranges have separate slopes and
offsets for computing SO
2
concentration.
The two ranges must be independently calibrated.
