Tormach 1500MX - Page 136

Note: Dropbox stops synchronizing once the PathPilot
controller’s internal drive has less than 500 MB of
free space. To avoid this, we recommend that you
organize your Dropbox account on a separate
computer before you connect to Dropbox with
PathPilot. Only store files in the top-level that you
want synchronized to your PathPilot controller.
To connect to Dropbox:
1. From the PathPilot interface, on the Main tab, in the
MDILine DROfield, type ADMINDROPBOX.
2. Select the Enter key.
The Dropbox Configuration application displays.
Figure 7-33: Dropbox Configuration application.
3. Select Install.
The Dropbox Installation dialog box displays.
4. Select OK.
Figure 7-34: Dropbox Installation dialog box.
The Dropbox installation starts and continues for about a
minute. When done, a web browser displays.
5. From the web browser, sign in or create a Dropbox
account.
The PathPilot controller connects to the Dropbox account,
creates a local Dropbox folder that is visible in File tab,
and synchronizes the folder.
6. Because Dropbox stops synchronizing once the PathPilot
controller’s internal drive has less than 500 MB of free
space, we recommend that you exclude large or
unrelated folders from synchronization. Select Exclude
Folder....
Figure 7-35: Exclude Folder button.
The Add Folder to Excluded Set dialog box displays.
7. In the Add Folder to Excluded Set dialog box, type the
name of the folder to exclude.
Figure 7-36: Add Folder to Excluded Set dialog box.
Note: You can only exclude folders, not
individual files.
8. Select OK.
9. Select Close.
The PathPilot controller is now connected to Dropbox.
©Tormach® 2024
Specifications subject to change without notice.
Page 136 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
7: PATHPILOT TOOLS AND FEATURES
