1: SAFETY
Workholding
Secure workpieces with appropriate workholding devices
(like a milling vise or strap clamps).
Verify that the workpiece is adequately secured.
Position clamps and workholding devices clear of any tool
paths.
Remove cutoff workpieces and other large chips before
starting the machine.
Never leave tools, stock, or other loose items inside the
machine.
1.4.3 Electrical Safety
WARNING! Electrical Shock Hazard: You must power
off the machine before making any electrical
connections. If you don't, there's a risk of
electrocution or shock.
Power off the machine before servicing.
Use an approved lockout/tagout system to secure the
machine's Main Disconnect in the OFF position before
servicing the machine.
Understand that certain electrical components can retain
dangerous electrical voltages, even after the machine is
powered off and all power is removed from the system.
Understand that certain installation, maintenance, and
troubleshooting procedures — for the machine and certain
accessories — require access to or modification of wiring
inside of the electrical cabinet. Only qualified electrical
machinery technicians shall perform these procedures.
Confirm that the mains voltage conforms to requirements
before connecting the machine.
For more information, see "Electrical and Power
Requirements" (page34).
Confirm that the machine installation meets all codes and
regulations of your locality.
Confirm that electrical connections are performed by a
certified electrician.
Lock the electrical cabinet door and remove the keys when
the machine is not being serviced to prevent unqualified or
unauthorized personnel from accessing the electrical
cabinet.
Never operate the machine with the electrical cabinet
door open.
Never reach into the electrical cabinet with the machine
powered on.
Never modify the machine's electronics.
Never drill into the electrical cabinet.
1.5 NOISE EXPOSURE
CAUTION! Noise Exposure Hazard: If you expect the
machine or the machining processes to exceed safe
exposure limits, you must wear ear protection.
With the axes moving and the spindle rotating (but not
cutting), the emission sound pressure level at the operator
control station is 70 dB(A).
Emission sound pressure levels vary depending on the
machining processes. Factors that influence the actual level of
noise exposure may include:
l Characteristics of the work room
l Other sources of noise (like the number of machines, or
other adjacent processes)
The permissible noise exposure level may vary between
countries. You must evaluate of the hazard and risk based on
your locality, and mitigate as necessary.
1.6 OPERATING MODES REFERENCE
This machine has two modes: run mode and setup mode. In
both modes, you must close and lock the enclosure doors
before starting a program. In setup mode, experienced
operators can perform maintenance or set up jobs while the
enclosure doors are open. To access setup mode, you must
have a key.
For unrestricted machine motion to occur, you must do the
following in the order listed:
1. Close the enclosure doors.
2. Command the machine to move or start a program. The
enclosure doors automatically lock before any machine
motion occurs.
1.6.1 Run Mode (Mode 1)
When the enclosure doors are open, and the machine is in run
mode, no motion can occur. For example, you can't jog the axis
or control the spindle.
©Tormach® 2024
Specifications subject to change without notice.
Page 25 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
