TROUBLESHOOTING
IN THIS SECTION, YOU'LL LEARN:
About common causes of failure in this machine, and our recommendations for diagnosing and
correcting them.
WARNING! Electrocution Hazard - Electrical Cabinet: Do not make or disconnect connections under
power.
Before operating the machine in any way, you must read and understand this section.
CONTENTS
11.1 Troubleshooting Safety 210
11.2 Getting Help 210
11.3 Required Tools 210
11.4 Frequently Found Problems 211
11.5 Electrical Service 212
11.6 Power Distribution Subsystem 214
11.7 Control Power Subsystem 215
11.8 Servo Drive Subsystem 217
11.9 Spindle Drive Subsystem 221
11.10 Servo IOBreakout Board Subsystem 227
To Next Page
