Tormach 1500MX - Space Planning Drawing - 1500 MX

34cm 14in
SPINDLE HEAD WIDTH
40cm 16in
MIST COLLECTOR WIDTH
0cm
0in
CHIP CONVEYOR
DISCHARGE HEIGHT
100cm
39in
156cm
61in
CONTROLLER SCREEN
C
L
84cm 33in
TABLE SURFACE
191cm
75in
ENCLOSURE TOP
239cm
94in
SPINDLE HEAD COVER AT Z+ LIMIT 257cm
101in
MIST COLLECTOR
274cm
108in
SIDE WINDOWS AT FULL OPENING 131cm
51in
SPINDLE NOSE AT Z+ LIMIT
297cm
117in
MIST COLLECTOR FILTER DOOR SWING 80cm 32in
DOOR BOTTOM
CHIP CONVEYOR
DISCHARGE WIDTH
24cm 10in
0cm
0in
ENCLOSURE FRONT
105cm
41in
ENCLOSURE REAR
139cm
55in
ELECTRICAL CABINET (DOOR CLOSED)
144cm
57in
CHIP CHUTE DISCHARGE
212cm
84in
COOLANT TANK
CHIP CONVEYOR
DISCHARGE
C
L
152cm
60in
47cm 19in
CONTROLLER SWING
SPINDLE
C
L
0cm
0in
ENCLOSURE 80cm 32in
CONTROLLER SWING 98cm 38in
ENCLOSURE 80cm 32in
55GAL. DRUM EXTENT 190cm 75in
131cm
52in
131cm 52in
219cm
86in
189cm
74in
ELECTRICAL CABINET (DOOR OPEN)
CHIP CONVEYOR
DISCHARGE 152cm
60in
MAIN DISCONNECT
OIL FILL CAP
ENCLOSURE FRONT 0cm 0in
COOLANT TANK 212cm 83in
ELECTRICAL CABINET
(DOOR CLOSED)139cm 55in
45cm 18in SPINDLE HEAD FRONT
121cm 48in SPINDLE HEAD REAR
63cm
25in
MIST COLLECTOR FRONT
103cm 40in
MIST COLLECTOR REAR
96cm 38in SIDE WINDOW REAR
30cm 12in SIDE WINDOW FRONT
0cm
0in
WINDOW OPENING 34cm
13in
WINDOW OPENING 93cm
36in
72cm 29in
WINDOW OPENING
159cm
62in
SIDE WINDOWS AT FULL OPENING
163cm
64in
WINDOW OPENING
191cm
75in
ENCLOSURE TOP
274cm
108in
SIDE WINDOWS AT FULL OPENING
297cm
117in
MIST COLLECTOR
FILTER DOOR SWING
257cm
101in
MIST COLLECTOR
MAIN DISCONNECT
NOTES
SOLID MODELS FOR SPACE PLANNING AVAILABLE
1.
FROM TORMACH DIMENSIONS BASED ON STACKUP OF COMPONENTS
2.
MAY VARY BY 12mm DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE
3.
CONTACT TORMACH PRESALES REGARDING
4.
SPECIALIZED ACCESS REQUIREMENTS
1500MX MILL OPTIONAL ACCESSORIES BASE MACHINE MAINTENANCE ACCESS DOOR CLEARANCE
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
DATE
DRAWN BY
TITLE:
SIZE
B
DWG. NO.
REV
SCALE: 1:30
A
1500MX MILL
SPACE PLANNING
SHEET 1 OF 1
51221
DO NOT SCALE DRAWING
THIS DRAWING CONTAINS PROPRIETARY AND CONFIDENTIAL INFORMATION BELONGING TO TORMACH INC. THIS DRAWING MAY NOT BE REPRODUCED OR COPIED IN WHOLE OR IN PART NOR CAN THE INFORMATION CONTAINED BE USED FOR ANY PURPOSE WITHOUT THE EXPRESS WRITTEN PERMISSION OF TORMACH INC
MCB
2023-02
4009 FELLAND ROAD, STE. 120 MADISON, WI 53718 (608) 849-8381
MATERIAL
N/A
