12.36 COOLANT TANK ASSEMBLY PARTS LIST
ID Description Alternative Part Number Quantity
1 Coolant Tank, 1500MX (PN52548) – 1
2 End Cover Panel, 1500MX Coolant Tank (PN52549) – 1
3 Chip Basket, 1500MX Coolant Tank (PN52550) – 2
4 Oil Skimmer Cover Panel, 1500MX Coolant Tank (PN52551) – 1
5 Coolant Pump Cover Panel, 1500MX Coolant Tank (PN52552) – 1
6 Coolant Pump Mounting Plate, 1500MX Coolant Tank, 1/4 hp, Fits
ASP-4180 (PN52553)
– 3
7 Fitting, Plug, 1 in. NPT, External Square Drive (PN52561) – 1
8 Removable Chip Screen, 1500MX Coolant Tank (PN52557) – 5
9 Locking Swivel Caster, 1500MX Coolant Tank (PN52554) – 4
10 Screw, Button Head Cap (Flanged), M5 × 0.8 - 10, Stainless Steel
(PN 38205)
McMaster-Carr: 97654A376 62
11 Screw, Button Head Cap (Flanged), M6 × 1 - 12, Stainless Steel
(PN 38206)
McMaster-Carr: 97654A380 16
12 Handle, Stainless Steel, 1500MX Coolant Tank Chip Baskets
(PN52562)
– 4
13 Screw, Button Head Cap, M4 × 0.7 - 8, Black Oxide Steel
(PN51317)
– 8
