Tormach 1500MX - Spindle Head Parts List

12: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 247 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
12.10 SPINDLE HEAD PARTS LIST
ID Description Alternative Part Number Quantity
1 Spindle Head Casting, 1500MX (PN51234) – 1
2 1500MX Spindle Cartridge Assembly, BT30, 10000 RPM, 5MHTD-
36T PULLEY, Through Spindle Coolant (CTS) (PN51347)
– 1
3 Spindle Motor Pulley, 1500MX (PN51235) – 1
4 Spindle Motor Mount Plate, 1500MX (PN51236) – 1
5 Power Drawbar Cylinder Assembly, 1500MX (PN51237) – 1
6 Spindle Index Sensor Bracket, 1500MX (PN51244) – 1
7 Spindle Motor Pulley Spacer, 1500MX (PN52217) – 1
8 Spindle Motor Pulley Washer, 1500MX (PN52218) – 1
9 Screw, Socket Head Cap, M8 × 1.25 - 30 (PN 30544) McMaster-Carr: 91290A434 4
10 Washer, Flat, M8 (PN 30531) McMaster-Carr: 91166A270 4
11 Screw, Socket Head Cap, M6 × 1 - 20 (PN 30832) McMaster-Carr: 91290A326 8
12 Washer, Flat, M6 (PN31676) McMaster-Carr: 91455A120 4
13 Screw, Socket Head Cap, M8 × 1.25 - 25 (PN34635) McMaster-Carr: 91290A432 6
14 Screw, Socket Head Countersunk, M8 × 1.25 - 20 (PN52222) McMaster-Carr: 91294A284 1
15* Coolant Ring Assembly, 1500MX (PN 51247) – 1
16** Spindle Head Camera Assembly, 1500MX (PN52463) – 1
17 Screw, Cup Point Set, M6 × 1 - 8 (PN30810) McMaster-Carr: 91390A127 1
18** Z-Axis Lubrication Assembly, 1500MX (PN51433) – 1
19** Proximity Sensor, PNP-NO, 3-Wire, 8 mm Body (PN51547) – 1
20* CTS Rotary Union, 1500MX (PN51604) – 1
21** Servo Motor, 1500 W, 220 V, 10.8 A, 3000 RPM, Oil Seal
(PN51152)
– 1
22** Belt, 1500MX Spindle (PN51735) Gates 800-5M-15
McMaster-Carr: 7939K26
1
* Optional accessory, not included with base machine.
**Component not included in this assembly, but shown here for context.
