Tormach 1500MX - Linear Actuator Assembly Parts List

12: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 249 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
12.12 LINEAR ACTUATOR ASSEMBLY PARTS LIST
ID Description Alternative Part Number Quantity
1 Servo Motor Mount, 80 mm Frame, 70 mm Pilot (PN51260) – 1
2 Ball Nut Bracket, 20 mm (PN51255) – 1
3 Ball Screw Support, Fixed-Side (PN51256) – 1
4 Ball Screw Support, Floating-Side, 15 mm ID, 45 mm Bore Height
(PN51261)
– 1
5 Coupler, Double Disc, 12 mm Bore × 19 mm Bore (PN51300) – 1
6 Ball Screw Assembly, 20 mm OD (PN51744 51279 51745) – 1
7 Spacer, Ball Screw Fixed Side Support, 25 mm OD × 15 mm ID × 10
mm Thick (PN51336)
– 2
8 Screw, Socket Head Cap, M6 × 1 - 20 (PN 30832) McMaster-Carr: 91290A326 10
9 Screw, Socket Head Cap, M5 × 0.8 - 16 (PN30546) McMaster- Carr: 91290A232 6
10 Screw, Socket Head Cap, M3 × 0.5 - 20 (PN38572) McMaster- Carr: 91290A123 2
11 Ball Screw Lock Nut, M15 × 1 (PN51307) Misumi: BNRC15 1
12 Servo Motor Mount Bumper (PN51302) – 1
13 Ball Screw Support Bumper (PN51303) – 1
14 Retaining Ring, External, OD, 15 mm (PN51338) McMaster- Carr: 98541A410 1
15 Servo Motor, 750W (PN51810 51810 51258) – 1
16 Servo Power Cable (PN51571 51572 51573) – 1
17 Servo Encoder Cable (PN51568 51569 51570) – 1
