12.34 SPINDLE HEAD CAMERA ASSEMBLY PARTS LIST
ID Description Alternative Part Number Quantity
1 Camera Bracket, 1500MX (PN52460) – 1
2 Camera Seal, 1500MX (PN52461) – 1
3 Camera Window, 1500MX (PN52462) – 1
4 Screw, Button Head Cap (Flanged), M6 × 1 - 12, Stainless Steel
(PN 38206)
McMaster-Carr: 97654A380 4
5 Camera, USB (PN51240) – 1
6 Screw, Pan Head Machine, M4 × 0.7 - 8, Zinc Plated (PN20001) McMaster-Carr: 92005A218 8
7 Washer, Flat, M4 (PN31087) McMaster-Carr: 91166A230 2
