12.5 ELECTRICAL CABINET PARTS LIST
ID Description Alternative Part Number Quantity
1 Electrical Cabinet, 1500MX (PN51284) – 1
2 Electrical Cabinet Door, 1500MX (PN51285) – 1
3 Electrical Cabinet Door Gasket, 1500MX (PN51669) – 1
4 Cam Lock, Zinc Plated, Hex Drive, Quarter-Turn Counterclockwise
to Open (PN51588)
McMaster-Carr: 2050N12 1
5 Hinge, Weld-On, Lift-Off Style, 1-7/16 in. Width (PN51314) – 2
6 Electrical Panel Back Plate, 1500MX (PN51287) – 1
7 Cable Gland Foam Bracket (PN51296) – 4
8 Cable Gland Strain Relief Bracket (PN51295) – 2
9 Screw, Button Head Cap (Flanged), M5 × 0.8 - 12 (PN38890) McMaster-Carr: 97654A377 16
10 Nut, Hex, M5 × 0.8 (PN 31201) McMaster-Carr: 90591A260 8
11 Foam Block, 30 mm × 80 mm (PN51313) – 4
12 Electrical Cabinet Doghouse, 1500MX (PN51311) – 1
13 Connector Bulkhead, Electrical Cabinet, Top Right Exit (PN51297) – 1
14 Connector Bulkhead, Electrical Cabinet, Bottom Right Exit
(PN51298)
– 1
15 Electrical Cabinet Accessory Cover Plate (PN37926) – 2
16 Screw, Button Head Cap, Flanged M8 × 1.25 - 10, 18-8 Stainless
(PN51324)
McMaster-Carr: 97654A683 4
17 Screw, Button Head Cap, Flanged M4 × 0.7 - 8, 18-8 Stainless
(PN51331)
McMaster-Carr: 97654A372 9
18 Inovance SV660N, AC Servo Drive, Ethercat, 220 Vac, 12 A, STO
Function (PN51195)
– 1
19 Inovance SV660N, AC Servo Drive, Ethercat, 220 Vac, 5.5 A, STO
Function (PN51259)
– 3
20* Inovance SV660N, AC Servo Drive, Ethercat, 220 Vac, 2.8 A, STO
Function, (PN51194)
– 0
21 Contactor (24 Vdc Coil, 1 Auxiliary Pole) (PN37343) – 1
22 Circuit Breaker (20 A, 2 Pole) (PN37345) – 2
23 Circuit Breaker (10 A, 2 Pole) (PN37346) – 1
24 Circuit Breaker (3 A, 2 Pole) (PN37516) – 1
25 Filter (110 Vac/250 Vac, 20 A) (PN37914) – 1
