12: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 237 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
ID Description Alternative Part Number Quantity
26 Terminal Block, GND, 4 Position, Spring Type, Internally Jumpered,
JUT3-4/2-2PE (PN51289 )
– 4
27 Terminal Block, 4 Position, Spring Type, Internally Jumpered,
NGMX, JUT3-4/2-2 (PN51290)
– 18
28 Power Supply (24 Vdc, 60 W) (PN50461) – 1
29 Din Rail (35 × 7.5), 375 mm Long (PN51633) McMaster-Carr: 8961K15 1
30 Din Rail (35 × 7.5), 300 mm Long (PN51634) McMaster-Carr: 8961K15 1
31 Servo IO Breakout Board (6 Axis) (PN51252) – 1
32 Main Disconnect Switch (PN30454) – 1
33 Fan (24 Vdc, 120 mm) (PN37526) McMaster-Carr: 8774N18 1
34 Thermal Switch (Pushbutton Reset) (PN37420) – 1
35 Spindle Brake Resistor (S4) (PN37906) – 1
36 Screw, Button Head Cap, M4 × 0.7 - 8, Black Oxide Steel
(PN51317)
McMaster-Carr: 91239A140 15
37 Bulkhead Label, Upper Bulkhead, 1500MX Electrical Cabinet
(PN51471)
– 1
38 Bulkhead Label, Upper Bulkhead, 1500MX Electrical Cabinet
(PN51472)
– 1
39 Standoff, 47 mm Hole Spacing, Clip-On Din Rail, Plastic (PN51473) – 2
40 Electrical Cabinet Exhaust Cover Retainer (PN37947) – 2
41 Electrical Cabinet Exhaust Filter (PN37948) – 2
42 IEC 320 Socket (Female, Single) (PN37350) – 2
43 IEC 320 Socket (Female, Double) (PN37351) – 3
44 Connector, 5 Pin, Female (PN37353) – 1
45 Connector, RJ45 Socket (PN37355) – 2
46 Circular Connector, M12, Rear Panel Mount, Plug, 4 Pin Female
(PN51293)
– 4
47 Circular Connector, Plug, 5 Pin Male, Metal Hose, Solder
(PN39263)
– 1
48 Cable Cord Grip M20 × 1.25 / 25 mm Nut (PN38758) – 1
49 Screw, Button Head Cap, M5 × 0.8 - 8 (PN34636) McMaster-Carr: 92095A207 4
50 Screw, Pan Head, Thread Forming M4 × 1.79 - 10, Zinc Plated
(PN51323)
McMaster-Carr: 90380A376 4
51 Screw, Button Head Cap, M5 × 0.8 - 10 (PN35774) McMaster-Carr: 91239A224 3
