Tormach 1500MX - Enclosure Door Assembly Parts List

12: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 243 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
12.6.4 Enclosure Door Assembly Parts List
ID Description Alternative Part Number Quantity
1 Enclosure Door Panel, 1500MX (PN51274) – 1
2 Sealing Strip (Self-Adhesive), 25 mm × 1.5 mm (PN51693) McMaster-Carr: 9023K81 1
3 Enclosure Door Window, 1500MX (PN51275) – 1
4 Long Window Clamp, Enclosure Door, 1500MX (PN51690) – 2
5 Short Window Clamp, Enclosure Door, 1500MX (PN51691) – 2
6 Linear Bearing Block, Round, 16 mm (PN37610) – 2
7 Linear Bearing Block, Supported Round, 16 mm (PN51817) – 2
8 Enclosure Door Linear Bearing Cover Panel, 1500MX (PN51886) – 1
9 Door Handle Bracket, 1500MX (PN51360) – 1
10 Door Handle, 1500MX (PN51361) – 1
11 Door Lock Latch Plate Bracket, 1500MX (PN51363) – 1
12 Locking Door Switch Latch Plate, 1500MX (PN51329) – 1
13 Enclosure Door Overlap Extension, 1500MX (PN51365) – 1
14 Push-In Bumper, 0.25 in. Stem, 0.22 in. Height (PN51367) McMaster-Carr: 9309K64 4
15 Push-In Bumper, 0.25 in. Stem, 0.38 in. Height (PN52210) McMaster-Carr: 9309K68 5
16 Decal Kit, Mill Enclosure Safety (PN38830) – 1
17 Screw, Button Head Cap, Flanged M8 × 1.25 - 16, 18-8 Stainless
(PN38468)
McMaster-Carr: 90909A479 2
18 Screw, Button Head Cap (Flanged), M5 × 0.8 - 10, Stainless Steel
(PN 38205)
McMaster-Carr: 97654A376 16
19 Screw, Button Head Cap (Flanged), M6 × 1 - 12, Stainless Steel
(PN 38206)
McMaster-Carr: 97654A380 10
20 Screw, Socket Head Countersunk, M6 × 1 - 12 (PN51432) McMaster-Carr: 91294A236 2
21 Screw, Socket Head Countersunk, M4 × 0.7 - 8 (PN51431) McMaster-Carr: 91294A188 2
22 Screw, Button Head Cap, Flanged M6 × 1 - 8, 18-8 Stainless
(PN51692)
McMaster-Carr: 97654A682 16
