12.26 Z-AXIS WAY COVER ASSEMBLY PARTS LIST
ID Description Alternative Part Number Quantity
1 Top Segment, Z-Axis Way Cover, 1500MX (PN51582) – 1
2 Middle Segment, Z-Axis Way Cover, 1500MX (PN51586) – 9
3 Bottom Segment, Z-Axis Way Cover, 1500MX (PN51589) – 1
4 Side Rail, Z-Axis Way Cover. 1500MX (PN51585) – 2
5 Liner, Z-Axis Way Cover, 1500MX (PN51670) – 1
6 Liner Clamp, Z-Axis Way Cover, 1500MX (PN51673) – 4
7 Screw, Button Head Cap (Flanged), M6 × 1 - 12, Stainless Steel
(PN 38206)
McMaster-Carr: 97654A380 4
