12.2 ASSEMBLY OVERVIEW PARTS LIST
ID Description Quantity
1 Base-Column Subassembly, 1500MX (PN51224) 1
2 Linear Rail, 25 mm, 760 mm Long, Precision H, M6 Top Down Mount (PN51340) 4
3 Pin, 4 × 20 (PN51342) 60
4 Linear Guide Rail Bolt Cap, M6, Plastic with O-Ring (PN51350) 52
5 Screw, Socket Head Cap, M6 × 1 - 20 (PN 30832) 54
6 Screw, Socket Head Countersunk, M6 × 1 - 20 (PN51321) 60
7 Linear Guide Block, 25 mm, Precision H, ZA Preload, Interchangeable, M6 Top Down Mount (PN51341) 8
8 Linear Actuator Assembly, 350 mm Travel, 10 mm Lead (PN51334) 1
9 Linear Actuator Assembly, 356 mm Travel, 5 mm Lead (PN 51335) 1
10 X-Axis Subassembly, 1500MX (PN51223) 1
11 Spindle Head Assembly, 1500MX (PN 51127) 1
12 Electrical Cabinet Assembly, 1500MX (PN 51228) 1
13 X-Axis Drag Chain, 1500MX (PN 51422) 1
14 Y-Axis Drag Chain, 1500MX (PN51423) 1
15 Z-Axis Drag Chain, 1500MX (PN51424) 1
16 X-Axis Drag Chain Guide, 1500MX (PN51767) 1
17 Y-Axis Drag Chain Guide, 1500MX (PN51773) 1
18 Z-Axis Way Cover Assembly, 1500MX (PN51204) 1
19 Y-Axis Rear Way Cover Assembly, 1500MX (PN51205) 1
20 Y-Axis Front Way Cover Assembly, 1500MX (PN51206) 1
21 X-Axis Sheet Metal Cover Assembly, 1500MX (PN 51231) 1
22 Saddle Cover Right/Left Panel, 1500MX (PN51448) 2
23 Spindle Head Sheet Metal Cover Assembly, 1500MX (PN51398) 1
24 Base-Column Rear Access Panel, 1500MX (PN51743) 1
25 Fan (24 Vdc, 120 mm) (PN37526) 1
26 Electrical Cabinet Exhaust Cover Retainer (PN37947) 1
27 Electrical Cabinet Exhaust Filter (PN37948) 1
28 Fan Guard, Wire (PN30515) 1
29 Screw, Phillips Head Countersunk, M4 × 0.7 - 40, Zinc Plated (PN51327) 1
30 Nut, Hex, M4, Zinc Plated (PN38358) 1
