12.6.2 Enclosure Kit Parts List
ID Description Alternative Part Number Quantity
1 Right Chip Tray, 1500MX (PN51263) – 1
2 Left Chip Tray, 1500MX (PN51264) – 1
3 Coolant Chute, 1500MX (PN51280) – 2
4 Chip Tray Support Bracket, 1500MX (PN52439) – 2
5 Right Rear Enclosure Panel, 1500MX (PN51265) – 1
6 Right Side Enclosure Panel, 1500MX (PN51267) – 1
7 Left Side Enclosure Panel, 1500MX (PN51268) – 1
8 Side Enclosure Panel Window Cover, 1500MX (PN51527) – 2
9 Right Front Enclosure Panel, 1500MX (PN51269) – 1
10 Center Front Enclosure Panel, 1500MX (PN51343) – 1
11 Left Front Enclosure Panel, 1500MX (PN51270) – 1
12 Right Top Enclosure Panel, 1500MX (PN51271) – 1
13 Left Top Enclosure Panel, 1500MX (PN51272) – 1
14 Linear Rail Support, Round, 16 mm (PN37622) – 2
15 Linear Rail, 16 mm Round, 1250 mm (PN51364) – 1
16 Linear Rail, Supported 16 mm Round, 1200 mm (PN51816) – 1
17 Locking Door Switch Bracket, 1500MX (PN51369) – 1
18 Locking Door Switch, 1500MX (PN51328) – 1
19 Enclosure Door Assembly, 1500MX (PN51273) – 1
20 Chip Tray Center Kick Plate, 1500MX (PN51374) – 1
21 Enclosure Scuff Guard, 1500MX (PN51345) – 1
22 ATC Mount Cover Panel, 1500MX (PN52207) – 1
23 Console Cable Cover, 1500MX (PN51382) – 1
24 Enclosure Mount Camera Bracket, 1500MX (PN51417) – 1
25 Air Gun Kit (PN51443) – 1
26 LED Flood Light (20 W) (PN51591) – 2
27 Flood Light and Window Retainer, 1500MX Enclosure (PN51507) – 4
28 Cable, IEC 320 Extension (IEC 320 C13 - IEC 320 C14), 2.0 m, 10 A
250 V 18/3 AWG SJT (PN38389)
– 2
29 Decal, Enclosure, 1500MX, Front Left Panel (PN51437) – 1
