12.24 SPINDLE HEAD SHEET METAL COVER ASSEMBLY PARTS LIST
ID Description Alternative Part Number Quantity
1 Spindle Head Front Panel, 1500MX (PN51241) – 1
2 Spindle Head Right Side Panel, 1500MX (PN51243) – 1
3 Spindle Head Left Side Panel, 1500MX (PN51474) – 1
4 Spindle Head Back Panel, 1500MX (PN51242) – 1
5 Spindle Head Top Panel, 1500MX (PN51475) – 1
6 Spindle Head Cover Mounting Bracket, 1500MX (PN51444) – 1
7 Spindle Head Access Panel, 1500MX (PN51769) – 1
8 Screw, Button Head Cap (Flanged), M6 × 1 - 12, Stainless Steel
(PN 38206)
McMaster-Carr: 97654A380 36
9** Push Button, 1NO1NC, White LED (PN51239) – 1
10** Fan (24 Vdc, 120 mm) (PN37526) McMaster-Carr: 8774N18 1
11** Electrical Cabinet Exhaust Cover Retainer (PN37947) McMaster-Carr: 19155K23 1
12** Electrical Cabinet Exhaust Filter (PN37948) McMaster-Carr: 19155K53 1
13** Fan Guard, Wire (PN30515) McMaster-Carr: 19155K96 1
14** Screw, Phillips Head Countersunk, M4 × 0.7 - 40, Zinc Plated
(PN51327)
McMaster-Carr: 91420A250 4
15** Washer, Flat, M4 (PN31087) McMaster-Carr: 91166A230 4
16** Nut, Hex, M4, Zinc Plated (PN38358) McMaster-Carr: 90591A255 4
* Optional accessory not included with base mill.
**Component not included in this assembly, but shown here for context.
