2: ABOUT YOUR MACHINE
©Tormach® 2024
Specifications subject to change without notice.
Page 30 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
2.1 MACHINE SPECIFICATIONS
Travels
X-Axis 19.7" (500 mm)
Y-Axis 13.8" (350 mm)
Z-Axis 14" (356 mm)
Spindle-to-Table MaximumClearance 17.7" (450 mm)
Spindle-to-Table Minimum Clearance 3.7"(96 mm)
Spindle Centerline to Machine Column 14.7"(370 mm)
Spindle
Spindle Power (Continuous) 4 hp (3 kW)
Spindle Power (4-Minute Overload) 6 hp (4.5 kW)
Spindle Maximum Speed 10,000 rpm
Transmission 5M Toothed Belt
Spindle Taper BT30
Thread Machining Rigid Tapping, Tension/Compression, Thread Mill
Maximum Feed Rate
X- and Y-Axis 1200 IPM(30.5 m/min)
Z-Axis 600 IPM(15.2 m/min)
Axis Motor Servo Driven
Power and Air
Primary Power Required
*
Single-Phase 230 Vac, 50/60 Hz
Recommended Circuit Amperage
*
30 A breaker
Plug Type NEMA L6-30P
Air Required 90-120 psi
Table
Table Size 35" × 12.75"(890 mm × 325 mm)
T-Slot Size 5/8" (15.9 mm) (three slots)
T-Slot Spacing 3.9"(100 mm)
Maximum Weight on Table 300 lb (136 kg)
Overall Dimensions
Machine Size
†
86" × 104"(2.2 m × 2.6 m)
Overall System Height
†
94" (2.4 m)
