12.28 Y-AXIS REAR WAY COVER ASSEMBLY PARTS LIST
ID Description Alternative Part Number Quantity
1 Base Segment, Y-Axis Rear Way Cover, 1500MX (PN51636) – 1
2 Moving Segment, Y-Axis Rear Way Cover, 1500MX (PN51637) – 1
3 Wide Slide Plate, Y-Axis Rear Way Cover, 1500MX (PN51644) – 2
4 Narrow Slide Plate, Y-Axis Rear Way Cover, 1500MX (PN51645) – 2
5 Screw, Socket Head Countersunk, M4 × 0.7 - 8, Stainless Steel
(PN51672)
McMaster-Carr: 92125A188 16
6 Washdown Cover Plate, Y-Axis Rear Way Cover, 1500MX
(PN51675)
– 1
7 Screw, Button Head Cap, M4 × 0.7 - 8, Stainless Steel (PN 50838) McMaster-Carr: 92095A189 3
