12.16 X-AXIS LUBRICATION ASSEMBLY PARTS LIST
ID Description Alternative Part Number Quantity
1 5-Port Manifold (PN30442) – 1
2 Screw, Button Head Cap, M6 × 1 - 20, Stainless Steel (PN 51700) McMaster-Carr: 92095A240 2
3 Tubing, Nylon, 4 mm OD (PN31304) McMaster-Carr: 50405K33 1
4 Lubrication Line, Copper, 1500MX X-Axis Ball Nut (PN52514) – 1
5 Lubrication Line, Copper, 1500MX X-Axis Bearing 1 (PN52515) – 1
6 Lubrication Line, Copper, 1500MX X-Axis Bearing 2 (PN52516) – 1
7 Lubrication Line, Copper, 1500MX X-Axis Bearing 3 (PN52517) – 1
8 Lubrication Line, Copper, 1500MX X-Axis Bearing 4 (PN52518) – 1
9 Fitting, Proportional Orifice, M8 × 1 (Male) - 4 mm (OD) Tube
(PN52511)
– 5
10 Fitting, Compression Nut, 4 mm Tube (PN 31310) – 7
11* Fitting, Ferrule, 4 mm Tube (PN31309) – 6
12 Fitting, Banjo Elbow, M6 × 1 - 4 mm Tube (PN31311) – 4
13 Fitting, Adapter, M6 × 0.75 P (Male) to M8 × 1 (Female)
(PN52512)
– 1
*Hidden inside fittings. See tube and ferrule connections reference in "Lubrication Assembly Exploded View" (page250).
