12.18 Y-AXIS LUBRICATION ASSEMBLY PARTS LIST
ID Description Alternative Part Number Quantity
1 Y-Axis Lubrication Manifold Bracket, 1500MX (PN51408) – 1
2 5-Port Manifold (PN30442) – 1
3 Lubrication Line, Copper, 1500MX Y-Axis Bearing 1 (PN52233) – 1
4 Lubrication Line, Copper, 1500MX Y-Axis Bearing 2 (PN52234) – 1
5 Lubrication Line, Copper, 1500MX Y-Axis Bearing 3 (PN52235) – 1
6 Lubrication Line, Copper, 1500MX Y-Axis Bearing 4 (PN52236) – 1
7 Lubrication Line, Copper, 1500MX Y-Axis Ball Nut (PN52231) – 1
8 Screw, Button Head Cap, Flanged M6 × 1 - 20, 18-8 Stainless
(PN51418)
– 2
9 Fitting, Proportional Orifice, M8 × 1 (Male) - 4 mm (OD) Tube
(PN52511)
– 5
10 Fitting, Banjo Elbow, M6 × 1 - 4 mm Tube (PN31311) – 4
11* Fitting, Ferrule, 4 mm Tube (PN31309) – 7
12 Fitting, Compression Nut, 4 mm Tube (PN 31310) – 7
13 Fitting, Adapter, M6 × 0.75 P (Male) to M8 × 1 (Female)
(PN52512)
– 1
14 Screw, Button Head Cap, M6 × 1 - 10, Stainless Steel (PN52513) McMaster-Carr: 92095A224 2
15 Fitting, Plug, M8 × 1, Compression Type (PN 53005) – 1
*Hidden inside fittings. See tube and ferrule connections reference in "Lubrication Assembly Exploded View" (page250).
