12: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 241 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
ID Description Alternative Part Number Quantity
30 Decal, Enclosure, 1500MX, Rear Right Panel (Interior) (PN51438) – 1
31 Label Kit, 1500MX Enclosure (PN52443) – 1
32 Left Rear Enclsoure Panel, 1500MX (PN51266) – 1
33 Panel Plug, Push-In, 32 mm (PN51383) McMaster-Carr: 9600K521 4
34 Panel Plug, Push-In, 6 mm (PN51530) McMaster-Carr: 9600K512 16
35 Enclosure Side Panel Trim, 1500MX (PN51375) – 2
36 Expandable Locking Grommet, 7/8 in. × 1 1/4 in. × 1/32 in. - 1/8
in., Nylon (White) (PN51519)
McMaster-Carr: 4946A704
McMaster-Carr: 4946A639
3
37 Push-In Bumper, 0.25 in. Stem, 0.22 in. Height (PN51367) McMaster-Carr: 9309K64 4
38 Screw, Button Head Cap (Flanged), M6 × 1 - 12, Stainless Steel
(PN 38206)
McMaster-Carr: 97654A380 175
39 Screw, Button Head Cap, Flanged M6 × 1 - 40, 18-8 Stainless
(PN51544)
McMaster-Carr: 90909A432 1
40 Screw, Button Head Cap, Flanged M4 × 0.7 - 8, 18-8 Stainless
(PN51331)
McMaster-Carr: 97654A372 4
41 Screw, Button Head Cap, Flanged M6 × 1 - 8, 18-8 Stainless
(PN51692)
McMaster-Carr: 97654A682 12
42 Screw, Button Head Cap, M5 × 0.8 - 12, Stainless Steel (PN37716) McMaster-Carr: 92095A210 4
43 Cable Tie, 4 in., Nylon, Black (PN31719) McMaster-Carr: 7130K52 20
