12: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 233 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
ID Description Quantity
31 Washer, Flat, M4 (PN31087) 1
32 Machine Pneumatics Assembly, 1500MX (PN51626) 1
33 Machine Foot Assembly, 1500MX (PN51309) 3
34 Serial Number Plate, 1500MX (PN51715) 1
35 Lubrication Assembly, 1500MX (PN52556) 1
36 Electrical Cabinet Spacer, 1500MX (PN51479) 4
37 Screw, Socket Head Cap, M12 × 1.75 - 80 (PN 51592) 4
38 Screw, Button Head Cap, M6 × 1 - 12, Stainless Steel (PN 51597) 10
39 Screw, Button Head Cap (Flanged), M6 × 1 - 12, Stainless Steel (PN 38206) 37
40 Screw Nail, #4 × 0.188 in., Stainless Steel (PN51517) 4
41 Washer, Flat, M6 (PN31676) 34
42 Screw, Button Head Cap, M6 × 1 - 20, Stainless Steel (PN 51700) 2
43 Screw, Button Head Cap, M3 × 0.5 - 8, Black Oxide Steel (PN51326) 4
44 Screw, Socket Head Cap, M5 × 0.8 - 16 (PN30546) 4
45 Screw, Socket Head Cap, M6 × 1 - 25 (PN 31685) 32
46 Screw, Socket Head Cap, M8 × 1.25 - 70 (PN51751) 12
47 Screw, Socket Head Cap, M10 × 1.5 × 50 (PN 31597) 4
48 Screw, Socket Head Cap, M10 × 1.5 - 35 (PN 31592) 4
