11: TROUBLESHOOTING
©Tormach® 2024
Specifications subject to change without notice.
Page 228 UM10811: 1500MX Operator's Manual (Version 0424A)
For the most recent version, see tormach.com/support
Identifier Servo Drive IOCable Identifier Inputs Outputs
DR4 Z-Axis IO-6 Enclosure Lock
Power Drawbar Button
Enclosure Door Lock
TSC Power
Z-Axis Brake
DR5 A-Axis IO-9
