X.25 Calls
Issue 5 - 04/01 6-11
This screen changes when the call is confirmed by the DTE.
X.25 CONNECT
RxPkt 0
TxPkt 0
L1 L2 L3
To send a packet, press . The number of packets
transmitted (TxPkt) is incremented. If a packet is received
the number of packets received (RxPkt) is incremented.
Ending a call
To end the call the ENTER ( ) key, the following screen is
displayed:
X.25 CLEARED
Cause 0
Diag -
L1 L2 L3
The cause and diagnostic codes are displayed. If there is
either no cause or diagnostic code a dash (-) is displayed.
