5 Using 3D Guidance in theField
Note – For more information on using the Select 3D Guidance Line dialog, see
Selecting a 3D line, page 119.
Use any of the following tools to move the cross-hairs in the Guide to
Horizontal Alignment dialog:
Use the arrow keys to move the cross-hairs around the screen.
To zoom the current view in and out, press + or -.
To resize the current view to the immediate area around the cross-hairs,
press Zoom Target.
To view all of the linework, press Zoom All.
All linework for the design, including the site map and any avoidance zones, is
shown in this dialog.
Tip – If several lines are grouped closely, press Zoom Target to zoom in for easier
selection. Alternatively, move the cross-hairs to an area where the lines are more easily
seen. To move the cross-hairs large distances across the screen, zoom out and then
hold down an arrow key. This lets you move rapidly across the design.
6. To select the line for horizontal guidance, press Select. The line closest to the
center of the cross-hairs is selected. The selected line appears as a thick red
line.
To deselect the current horizontal alignment without selecting another line,
press Deselect.
7.
To confirm the settings, press \; to exit without saving changes, press =.
A guidance screen appears.
140 GCS900 GradeControl System for Excavators Operator's Manual
