4-19
Maintenance ＞ Assembly and disassembly
4
Pull out the cassette (a).
5
Open the front cover (a).
6
Detach the left cover.
1 Remove screw (a) for the lower left cover. (M3x8)
2 Release two hooks (c).
3 Release 2 hooks (d).
4 Hold up the left cover and release 4 hooks (e) then remove the cover.
a
a
