(6-2)Part name table (Other parts)
No. Name used in service manual Name used in parts list Part. No.
1 Paper feed clutch PARTS CLUTCH 20-2W Z35R
(PARTS DRIVE FEED ASSY SP)
302LV9416_
(302LV9425_)
2 Registration clutch CLUTCH 50 Z35R 302KV4404_
3 Developer clutch CLUTCH 50 Z35R 302KV4404_
4 Conveying clutch PARTS CLUTCH 35 Z35R SP
(PARTS DRIVE FEED ASSY SP)
302NR9401_
(302LV9425_)
5 Duplex clutch PARTS CLUTCH 20-2W Z35R 302LV9416_
6 MP solenoid -
(PARTS DRIVE FEED ASSY SP)
-
(302LV9425_)
7 Feedshift solenoid*1 -
(PARTS HIGH VOLTAGE UNIT SP)
(PARTS HIGH VOLTAGE UNIT SP)
-
(302L29403_)*1
(302LV9406_)*2
8LCD -
(PARTS PWB ASSY PANEL SP)
-
(302TP9410_)
9 Cleaning lamp -
(DK-3171(J))
(DK-3172(U))
(DK-3170(E))
(DK-3174(AO))
(DK-3191(J))
(DK-3192(U))
(DK-3190(E))
(DK-3194(AO))
-
(302T99308_)*5,*1
(302T99307_)*5,*2
(302T99306_)*5,*3
(302T99309_)*5,*4
(302T69305_)*9,*1
(302T69304_)*9,*2
(302T69303_)*9,*3
(302T69306_)*9,*4
10 Fuser heater 1 -
(FK-3201)
(FK-3202)
(FK-3200)
(FK-3301)
(FK-3302)
(FK-3300)
-
(302V393050)*5,*1
(302V393060)*5,*2
(302V393040)*5,*3,*4
(302TP93020*9,*1
(302TA93050)*9,*2
(302TA93040*9,*3,*4
11 Fuser heater 2 -
(FK-3201)
(FK-3202)
(FK-3200)
(FK-3301)
(FK-3302)
(FK-3300)
-
(302V393050)*5,*1
(302V393060)*5,*2
(302V393040)*5,*3,*4
(302TP93020*9,*1
(302TA93050)*9,*2
(302TA93040*9,*3,*4
12 Fuser thermostat 1 -
(FK-3201)
(FK-3202)
(FK-3200)
(FK-3301)
(FK-3302)
(FK-3300)
-
(302V393050)*5,*1
(302V393060)*5,*2
(302V393040)*5,*3,*4
(302TP93020*9,*1
(302TA93050)*9,*2
(302TA93040*9,*3,*4
