1-9
Specifications Parts names
[CONFIDENTIAL]
(4) Operation Panel Keys
SelectKey :
Selectsthemenu
displayedatthebottomof
themessagedisplay.
Numerickeys.
Enternumbersandsymbols.
DisplaystheDocumentBox
screen.
Exitstheoperationforthe
currentuser(i.e.logout).
Cancelsorpausesthejobin
progress.
Messagedisplay :
Displaysthesettingmenu
anderrormessages.
SelectKey :
Selectsthemenu
displayedatthebottom
ofthemessagedisplay.
Lightsupintheprintreadystate.
Blinksduringprintprocessingorwhenanerroroccurs.
Lightsupwhenthemachineisinenergysavemode.
Lightsorblinkswhenanerroroccursandajobisstopped.
DisplaystheMenuscreen.
Incrementsordecrements
numbers,orselectsmenuin
themessagedisplay.In
addition,movesthecursor
whenenteringthecharacters.
Finalizesafunctionormenu,
andnumbersthathavebeen
entered.
Returnstotheprevious
display.
