Utax P-4532DN - (4-2) Part name table (Sensors and Switches)

3-11
Machine Design ＞ Electric parts
[CONFIDENTIAL]
*1:60/55/50 ppm model
*2:45 ppm model
(4-2)Part name table (Sensors and Switches)
18 Rear cover switch
Detects the opening and closing of the rear cover.
19 Waste toner sensor
Detects when the waste toner box is full.
20 Power source switch
Change ON/OFF the power supply of a main PWB, an operation PWB,
etc.
No. Name used in service manual Name used in parts list Part. No.
1 Paper sensor 1 -
(PARTS HIGH VOLTAGE UNIT SP)
(PARTS HIGH VOLTAGE UNIT SP)
-
(302L29403_)*1,*2
(302LV9406_)*3
2 Paper sensor 2 -
(PARTS HIGH VOLTAGE UNIT SP)
(PARTS HIGH VOLTAGE UNIT SP)
-
(302L29403_)*1,*2
(302LV9406_)*3
3 Cassette size switch SW.PUSH 7SP03072001+H01
4 Eject full sensor PARTS SENSOR OPT SP 302P79401_
5 Registration sensor 1 *2 -
(PARTS HIGH VOLTAGE UNIT SP)
(PARTS HIGH VOLTAGE UNIT SP)
-
(302L29403_)*1,*2
(302LV9406_)*3
6 Registration sensor 2 *1 -
(DK-3171(J))
(DK-3172(U))
(DK-3170(E))
(DK-3174(AO))
(DK-3191(J))
(DK-3192(U))
(DK-3190(E))
(DK-3194(AO))
-
(302T99308_)*5,*1
(302T99307_)*5,*2
(302T99306_)*5,*3
(302T99309_)*5,*4
(302T69305_)*9,*1
(302T69304_)*9,*2
(302T69303_)*9,*3
(302T69306_)*9,*4
7 Registration sensor 3 *1 -
(PARTS HIGH VOLTAGE UNIT SP)
(PARTS HIGH VOLTAGE UNIT SP)
-
(302L29403_)*1,*2
(302LV9406_)*3
8 Duplex sensor 1 *1 PARTS SENSOR OPT SP
(PARTS COVER REAR ASSY SP JP)
(PARTS COVER REAR ASSY SP)
303M89426_
(302TP9406_)
(302TP9402_)
9 Duplex sensor 2 -
(PARTS HIGH VOLTAGE UNIT SP)
(PARTS HIGH VOLTAGE UNIT SP)
-
(302L29403_)*1,*2
(302LV9406_)*3
10 MP paper sensor PARTS SENSOR OPT SP 303M89426_
