Utax P-4532DN - (3-3) Connector lists

8-13
PWBs ＞ Description for PWB
[CONFIDENTIAL]
(3-3)Connector lists
Destination
• YC1: Inlet
• YC2: Fuser unit
• YC3: Engine PWB
Connector Pins Signal I/O Voltage Description
YC1 1 LIVE I AC100V or 230V AC power input
2 NEUTRAL I AC100V or 230V AC power input
YC2 1 NEUTRAL1 I AC100V or 230V Fuser heater
2 LIVE O AC100V or 230V ACPower source
3 NEUTRAL2 I AC100V or 230V Fuser heater
YC3 1 +24V0 O DC24V Power source
2 +24V0 O DC24V Power source
3 +24V0 O DC24V Power source
4 +24V0 O DC24V Power source
5 GND - - Ground
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
9 PSLEEPN I DC0V/5V Sleep mode signal
10 RELAY I DC0V/5V Relay control
11 ZCROSSN O DC0V/5V (pulse) Zero crossing signal
12 HEAT1REM I DC0V/24V Fuser heater control
13 HEAT2REM I DC0V/24V Fuser heater control
