Utax P-4532DN - (6-3) Connector lists

8-19
PWBs ＞ Description for PWB
[CONFIDENTIAL]
(6-3)Connector lists
Destination
• YC1: Engine PWB
• YC2: Engine PWB
• YC3: Drum connect PWB
• YC4: LSU fan motor
• YC7: Waste toner sensor
• YC8: MP paper sensor
• YC9*1: Duplex sensor 1
• YC10: Rear cover switch
• YC11: Fuser pressure release motor
• YC12: Eject motor
• YC13*1: Feed shift solenoid
*1: 50/55/60 ppm model
Connector Pins Signal I/O Voltage Description
YC1 1 EECLK I DC0V/3.3V (pulse) Clock signal
2 GND - - Ground
3 EESIO I/O DC0V/3.3V Data signal
4 ERASER I DC0V/3.3V CL control signal
5 +3.3V3_F2 I DC3.3V Power input
6 TSENS O Analog Toner sensor output signal
7 SBMDIR I DC0V/5V Eject motor: On/Off
8 WTSENS O Analog Waste toner sensor output signal
9 SBMENBLN I DC0V/3.3V Output control signal
10 WTLED I DC0V/3.3V Waste toner LED control
11 SBMSTEP I DC0V/3.3V Step signal
12 MPFSENS O DC0V/3.3V MP paper sensor: On/Off
13 SBMMODE I DC0V/3.3V Mode control signal
14 +3.3V1_PWM_F2 I DC3.3V Power input
15 TMOT I DC0V/3.3V Toner motor: On/Off
16 LFANN I DC0V/24V LSU fan motor: On/Off
17 FUDR I DC0V/24V Feedshift solenoid: On/Off
18 ENVMOT I DC0V/5V Fuser pressure release motor: On/Off
19 FDDR I DC0V/24V Feedshift solenoid: On/Off
20 DUJAMSEN1N O DC0V/3.3V Duplex sensor 1: On/Off
21 REGSEN2 O DC0V/3.3V Registration sensor 2: On/ Off
22 REARSWN O DC0V/3.3V Rear cover switch: On/Off
YC2 1 1WIRE - - -
2 +24V3_IL_F5 I DC24V Power input
3 GND - Ground
4 GND - Ground
5 +24V0_F3 I DC24V Power input
YC3 1 1WIRE - - -
2 TSENS I Analog TS output signal
