Utax P-4532DN - (4) Connecting the cable; (4-1) Connecting LAN Cable; (4-2) Connecting at USB

2-7
Installation ＞ Installing the main unit
[CONFIDENTIAL]
(4) Connecting the cable
(4-1)Connecting LAN Cable
1
Connect the cable to the machine.
1 Connect the network cable to the network interface connector located on the back side of the main unit.
2 Connect the other end of the cable to the network router.
(4-2)Connecting at USB
1
Connect the cable to the machine.
1 Connect the USB cable to the USB interface connector located on the back side of the main unit.
2 Connect the other end of the cable to the PC.
Important
If the power is on, turn the power switch off.
Important
If the power is on, turn the power switch off.
