Utax P-4532DN - 3 - 5 Drive system; (1) Drive configuration

3-22
Machine Design ＞ Drive system
[CONFIDENTIAL]
3 - 5 Drive system
(1) Drive configuration
Entire drive
60/55/50 ppm model
Paper feed roller
Faceup roller
Drum
Developer roller
Transfer roller
Middle feed roller
Main motor
Eject motor
Drum motor
Upper eject
roller
Lower eject
roller
Registration roller
DU conveying
roller
DU conveying
roller
Charger roller
Heat roller
Cleaning roller
Eject roller
