Utax P-4532DN - (2) 45 ppm model

3-2
Machine Design ＞ Mechanical Configuration
[CONFIDENTIAL]
(2) 45 ppm model
1 Cassette
2 Cassette paper feed section
3 Paper feed conveying section
4MP tray
5 MP tray paper feed section
6 Toner container
7 Developer unit
8 Laser scanner unit (LSU)
9 Charger roller unit
10 Drum unit
11 Transfer/Separation section
12 Eject tray (facedown)
13 Eject section
14 Eject conveying section
15 Fuser unit
16 Duplex conveyning section
10 1196 128
13
15
2
1
16
3
14
7
4
5
Light path
Paper path
Paper path (option)
