Utax P-4532DN - (3) Drum section; (3-1) Charger roller unit

3-28
Machine Design ＞ Mechanical construction
[CONFIDENTIAL]
Block diagram
*1: 45 ppm model
*2: 60/55/50 ppm model
(3) Drum section
(3-1)Charger roller unit
In the main charger section, the main charger roller with the electric charge contacts the drum surface and rotates to
charge the drum evenly.
YC4-1
YC4-2
YC4-3
YC4-4
YC5-6
MMOTCW
MMOTRDYN
MMOTCLKN
MMOTONN
REGCLN
6
5
4
3
Registration clutch
Engine PWB
YC2-21YC3-10
Registration sensor 3 *2
REGSEN2
YC19-12
Drum relay PWB
Relay-L PWB
REGSENSN
Registration sensor 2 *2
REGSEN2
Drum relay PWB
YC6-2
Drum PWB
YC5-8
MIDCLN
Conveying clutch
Registration sensor 1 *1
Main motor
1
2
3
4
2
3
4
1
