Utax P-4532DN - (5) Optical section; (5-1) Laser scanner section

3-32
Machine Design ＞ Mechanical construction
[CONFIDENTIAL]
Block diagram
(5) Optical section
(5-1)Laser scanner section
The charged surface of the drum is then scanned by the laser beam from the laser scanner unit. The laser beam is
dispersed as the polygon motor revolves to reflect the laser beam over the drum. Various lenses and mirror are housed
in the laser scanner unit, adjust the diameter of the laser beam, and focalize it at the drum surface.
MMOTCW
MMOTRDYN
MMOTCLKN
MMOTONN
HVCLK
EESIO
TSENS
YC3-2
YC4-1
TMOT
EECLK
1WIRE
TSENS
TMOT
YC2-6
YC2-15
Relay-L PWB
DLPCLN
Developer clutch
Toner sensor
Toner motor
YC5-2
Drum PWB
Drum relay PWB
High voltage PWB
YC2-1
YC4-1
YC4-2
YC4-3
YC4-4
YC19-7
YC2-3
YC2-1
Developer bias
Drum
EnginePWB
BDCNT
YC19-8
BACNT
YC19-9
6
5
Main motor
4
3
Container relay PWB
1
2
3
4
5
