Utax P-4532DN - (4) PWBs

4-25
Maintenance ＞ Assembly and disassembly
[60/55/50ppm]
45 ppm
(4) PWBs
Caution
Before replacing the PWB, be sure to take the following procedures. Otherwise, The PWB may get damaged.
Disconnect the power cord.
Press the power switch one second or more. (discharge the electric charge inside the main unit)
