Utax P-4532DN - (6) Transfer;Separation section

3-33
Machine Design ＞ Mechanical construction
[CONFIDENTIAL]
Block diagram
(6) Transfer/Separation section
The transfer and separation section consists mainly of the transfer roller and separation electrode.
A high voltage generated by the high voltage PWB is applied to the transfer roller for transfer charging.Paper after
transfer is separated from the drum by applying separation charging that is output from the high voltage PWB to the
separation electrode.
1 Polygon motor
2fθ main lens
3 Direction change mirrer
4 LSU dust shield glass
5LSU base
1
5
2
3
4
YC15-3
YC15-4
YC15-5
YC16-2
YC16-3
YC16-4
YC16-5
YC16-7
PLGDRN
PLGRDYN
POLCLK
VDATA1P
VDATA1N
VDATA2P
VDATA2N
SAMPLEN2
YC16-6 YC2-2
PD PW
SAMPLEN1 PDN
3
2
Polygon motor
1
APC PWB
Engine PWB
sensor
Laser
diode
Drum
Laser light
YC16-8
OUTPEN
YC16-9
VCONT1
YC16-10
VCONT2
32
1
4
