Utax P-4532DN - (3-2) Part name table (PWB)

3-9
Machine Design ＞ Electric parts
[CONFIDENTIAL]
(3-2)Part name table (PWB)
*1: 100V、*2: 120 V、*3: 220-240 V、*4: 240 V、*5: 45 ppm model、*6: 50 ppm model、*7: 55 ppm model、*8: 60 ppm model、*9:
50/55/60 ppm model
No. Name used in service manual Name used in parts list Part. No.
1 Main PWB PARTS PWB ASSY MAIN SP
PARTS PWB ASSY MAIN SP EU
302TP9408_*1,*2
302TP9407_*3
2 Engine PWB PARTS PWB ASSY ENGINE SP
PARTS PWB ASSY ENGINE SP
PARTS PWB ASSY ENGINE SP
PARTS PWB ASSY ENGINE SP
302TT9403_*5
302TS9401_*6
302TR9401_*7
302TP9409_*8
3 Power source PWB PARTS UNIT POWER SUPPLY 120 SP
PARTS UNIT POWER SUPPLY 230 SP
302T69410_*1,*2
302T69411_*3
4 High voltage PWB PARTS HIGH VOLTAGE UNIT SP
PARTS HIGH VOLTAGE UNIT SP
302L29403_*1,*2
302LV9406_*3
5 Drum PWB -
(DK-3171(J))
(DK-3172(U))
(DK-3170(E))
(DK-3174(AO))
(DK-3191(J))
(DK-3192(U))
(DK-3190(E))
(DK-3194(AO))
-
(302T99308_)*5,*1
(302T99307_)*5,*2
(302T99306_)*5,*3
(302T99309_)*5,*4
(302T69305_)*9,*1
(302T69304_)*9,*2
(302T69303_)*9,*3
(302T69306_)*9,*4
6 Drum relay PWB PARTS PWB ASSY DRUM CONNECT SP 302T69408_
7 Relay-L PWB PARTS PWB ASSY CONNECT-L SP
PARTS PWB ASSY CONNECT-L SP
302T99404_*5
302T69407_*9
8 Operation PWB PARTS PWB ASSY PANEL SP 302TP9410_
9 Backlight PWB -
(PARTS PWB ASSY PANEL SP)
-
(302TP9410_)
10 Fuser thermistor relay PWB PARTS PWB ASSY TH CONNECT SP 302LV9422_
11 APC PWB -
(LK-3170)
(LK-3190)
-
(302T99304_)*5*6
(302T69301_)*7*8
12 PD PWB -
(LK-3170)
(LK-3190)
-
(302T99304_)*5*6
(302T69301_)*7*8
13 Container relay PWB -
(DK-3171(J))
(DK-3172(U))
(DK-3170(E))
(DK-3174(AO))
(DK-3191(J))
(DK-3192(U))
(DK-3190(E))
(DK-3194(AO))
-
(302T99308_)*5,*1
(302T99307_)*5,*2
(302T99306_)*5,*3
(302T99309_)*5,*4
(302T69305_)*9,*1
(302T69304_)*9,*2
(302T69303_)*9,*3
(302T69306_)*9,*4
