Utax P-4532DN - (4-3) Connector lists

8-15
PWBs ＞ Description for PWB
[CONFIDENTIAL]
(4-3)Connector lists
Destination
• CN1: Engine PWB
• CN2: Fuser pressure release sensor
Connector Pins Signal I/O Voltage Description
YC101 1 +24V3_IL O DC24V Power source
2 TCNT O AnalogV Transfer control
3 TRREM O DC0V/3.3V Transfer remote signal
4 SCNT O Analog Separation control
5 +3.3V3_F2 O DC3.3V Power source
6 DUJAMSEN2N I DC0V/3.3V Duplex sensor 2: On/Off
7 REGSENSN I DC0V/3.3V Registration sensor: On/Off
8 PAPERSEN1N I DC0V/3.3V Paper sensor 1: On/Off
9 PAPERSEN2N I DC0V/3.3V Paper sensor 2: On/Off
10 BACNT I Analog Developer AC control
11 BDCNT I Analog Developer DC control
12 HVCLK O DC0V/3.3V Developer clock signal
13 MDCCNT I Analog Charger DC control
14 MACCNT I Analog Charger AC control
15 MHVCLK O DC0V/3.3V Charger clock signal
16 MISENS O Analog Charger current detection
17 GND - - Ground
18 ENVSENSN I DC0V/3.3V Eject sensor: On/Off
YC102 1 +3.3V14 O DC3.3V Power source
2 GND - - Ground
3 ENVSENSN I DC0V/3.3V Fuser pressure release sensor: On/Off
