Utax P-4532DN - (3) Exit section; (3-1) Detaching and refitting the exit unit

4-24
Maintenance ＞ Assembly and disassembly
(3) Exit section
(3-1)Detaching and refitting the exit unit
1
Remove the right cover.
(See Page 4-15)
2
Detach the left cover.
(See Page 4-18)
3
Detach the top cover assembly.
(See Page 4-21)
4
Detach the wire guide 1.
(See Page 4-28)
5
Detach the controller box cover.
(See Page 4-32)
6
Detach the exit unit
1 Pull the connector (f) out.
2 Pull the connector (a) out and then release the wires (c) from hooks.
3 Remove three screws (d) and then detach the exit unit (e).
4 Check or replace the exit unit and refit all the removed parts.
Important
• Wear anti-static wrist band to avoid from static shock on the laser scanner unit. Do not touch APC PWB and
terminal of FCC.
• Pay attention to insert FCC completely when connect it. If miss the connection, error comes up and takes
time to fix it.
