1-2
Specifications ＞Specifications
[CONFIDENTIAL]
*1 Up to upper limit height line in the cassette.
Developer
system
Mono component dry developing method
Toner replenishing: Automatic from the toner container
Transfer system Transfer roller method
Separation system Small diameter separation, dischager needle (DC bias)
Cleaning system Counter blade cleaning + cleaning roller
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system Heat and pressure fusing with the heat roller and the press roller
Heat source: halogen heater
Abnormally high temperature protection devices: thermostat
Memory 512 MB (On-Board )
Maximum: 3072 MB (On-Board +2048MB DIMM)
Interface Standard USB Interface Connector: 1 (Hi-Speed USB)
Network interface: 1 (10 BASE-T/100 BASE-TX/1000 BASE-T)
USB Port: 2 (Hi-Speed USB)
Option eKUIO: 1
Operating
Environment
Temperature 10 to 32.5°C/50 to 90.5°F
Humidity 15 to 80 %
Altitude 3,500 m/11,482 ft maximum
Brightness 1,500 lux maximum
Dimension (W × D × H) 14.97" × 16.16" ×
11.24"
380 × 410 × 285
mm
14.97" × 16.16" × 12.61"
380 × 410 × 320 mm
Weight (without toner container) Approx. 31.1 lb/
Approx. 14.1 kg
Approx. 33.8 lb/Approx. 15.3 kg
Space Required (W × D)
(Using multi purpose tray)
14.97" × 23.36"
380 × 613 mm
Power Source
AC100V、50/60Hz
11.4A - - 11.9A
AC120V、60Hz
9.5 A 10.0 A 10.0 A -
AC220-240V、
50Hz
5.4A 5.6 A 5.6 A -
Item
Description
45 ppm 50 ppm 55 ppm 60 ppm
