8-3
PWBs ＞ Description for PWB
[CONFIDENTIAL]
YC7 15 OPEN - - NC
16 OPEN - - NC
17 GND - - Ground
18 DP I/O Analog USB data signal
19 DN I/O Analog USB data signal
20 VBUS O DC0V/3.3V VBUS
signal
YC9 P1 TD1+ I/O Analog Send data
P2 TD1- I/O Analog Send data
P3 TD2+ I/O Analog Send data
P4 TD2- I/O Analog Send data
P5 CT1 I Center tap
P6 CT2 I Center tap
P7 TD3+ I/O Analog Send data
P8 TD3- I/O Analog Send data
P9 TD4+ I/O Analog Send data
P10 TD4- I/O Analog Send data
YC31 1 +3.3V2 O DC3.3V Power source
2 +5.0V2 O DC5.0V Power source
3 P1284DIR O DC0V/3.3V Direction input signal
4 NACK O DC0V/3.3V Acknowledge input signal
5 BUSY O DC0V/3.3V Busy input
6 PERROR O DC0V/3.3V Errer signal
7 SELECT O DC0V/3.3V Select signal
8 NFAULT O DC0V/3.3V Errer signal
9 PDATA1 I/O DC0V/3.3V Data signal
10 PDATA2 I/O DC0V/3.3V Data signal
11 PDATA3 I/O DC0V/3.3V Data signal
12 PDATA4 I/O DC0V/3.3V Data signal
13 PDATA5 I/O DC0V/3.3V Data signal
14 PDATA6 I/O DC0V/3.3V Data signal
15 PDATA7 I/O DC0V/3.3V Data signal
16 PDATA8 I/O DC0V/3.3V Data signal
17 NSELECTIN I DC0V/3.3V Select signal
18 NSTROBE I DC0V/3.3V Output signal
19 NAUTOFD I DC0V/3.3V AUTO-FEED signal
20 NINIT I DC0V/3.3V Reset signal
21 PDATECT I DC0V/3.3V OP detection signal
22 GND - - Ground
YC32 1 +24V0 I DC24V Power input
2 +24V0 I DC24V Power input
3 +24V0 I DC24V Power input
4 +3.3V0_PM O DC3.3V Power source
5 +3.3V3_E O DC3.3V Power source
6 +3.3V3_E O DC3.3V Power source
7 +5.0V1_C1 O DC5.0V Power source
8 +3.3V1_C O DC3.3V Power source
9 LEDPWM_EN O DC0V/3.3V(pulse) PI / Sensor intermittent control signal
Connector Pins Signal I/O Voltage Description
